细线伸线机带连续退火
| 退火镀锡机Continuous annealing tin-coating machine | |||||
| 特点：退火炉内炉膛设计炉温部分均匀，节能效果良好。双锡炉设计，产品可多样化同时生产。双层式卷曲机设计，节能设备使用面积 | |||||
| Main featrue:Add one inside the annealer, can make the temperture Impartial distribution.Dual tinning tank design .It can produce two kind of tin-coating copper wire in the same time.Spooler arranged in double layer can save space | |||||
| 管道退火镀锡技术参数Annealling and Tinning Machine | |||||
| 产品型号Mainchine type | 12H | 32H | 40H/4.5 | 40H/6 | 40H/7.5 |
| 生产头数NO of wire | 12 | 32 | 40 | 40 | 40 |
| 生产线径Wire Dia(mm) | ф3.5-ф1.05 | ф0.038-ф0.07 | ф0.08-ф0.32 | ф0.10-ф0.65 | ф0.1-ф0.7 |
| 放线方式Pay-off Stand | 越端式Overhead | 毛刷放线Brush | 毛刷放线或越端放线Brush or overhead | ||
| 最高机械速度Max.speed(m/min) | 100 | 300 | 300 | ||
| 退火方式Annealing Type | 无 | 电热辐射加热管道退火+水封保护Radiation heating | |||
| 镀锡方式Tinning Type | 双炉热镀（立镀）Hot coating | 双炉热镀（横镀）Hot coating | |||
| 放线盘尺寸Pay-off Bobbin Size(mm) | ф300-ф630 | ф250 | ф300 | ||
| 收线方式Take-up Type | 落桶式Pail spooler | 单盘力矩放线Single drive by torque motor | |||
| 排线方式Take-up Type | 梅花式成圈排线Coilling type | 减速电机+变频调速Motor +inverter control | |||
| 收线盘吃尺寸Take-up Bobbin Size | ф300×ф150×365 | 4-5 | 5-8 | 5-10 | 5-10 |
| 总装机功率Total Power(KW) | 20 | 45 | 50 | 65 | 75 |
