Bandwidth DC to 25MHz (-3dB)
Attenuation Ratio 1:10/100
Accuracy ±2%
Rise Time
Input Impedance
14ns
4MΩ//5.5pF each side to ground
Input Voltage
-Differential Range ±70V(DC+Peak AC) or 70Vrms @1/10
±700V(DC+Peak AC) or 700Vrms @1/100
- Common Mode Range
±700V(DC+Peak AC) or 700Vrms @1/10 & 1/100
- Absolute Max. Voltage ±1400V(DC+Peak AC) or 1000Vrms CAT III
(either input to ground)
Output Voltage
@1/10& 1/100 (Differential or Common Mode)
- Swing ±7V (into 1MΩ load)
- Offset (typical) <±5mV
- Noise (typical) 0.7mVrms
- Source Impedance (typical) 5 0 Ω ( f o r u s in g 1 MΩ input system oscilloscope)
CMRR (typical) -86dB @50Hz, -66dB @20kHZ
Ambient Operating Temperature -10 to 40
Ambient Storage Temperature -30 to 70
Ambient Operating Humidity 2 5 t o 85% RH
Ambient Storage Humidity 25 to 85% RH
Power Requirements*
- Standard 4xAA cells
- Options Power leads, Mains adaptor* (6VDC/60mA
Length of BNC Cable
or regulated 9VDC/40mA), USB power cord
95cm
Length of Input Leads 4 5 cm
Weight 400gms (probe and PVC jacket)
Dimensions (LxWxH) 170mm x 63mm x 21mm
