PT-8020

Attenuation:1:100/1000

Bandwidth                    DC to 70MHz(-3dB)

Accuracy                     ±2%

Input Impedance               10MΩ//10pF each side to ground

Input Voltage

-Differential Range*            ±1400V(DC+Peak AC)or 1400Vrms@1/100

                             ±14000V(DC+Peak AC)or 5000Vrms@1/1000

-Common Mode Range*         ±7000V(DC+Peak AC)or 2500Vrms@1/100 &1/1000

-Absolute Max.Voltage*         ±7000V(DC+Peak AC)or 2500Vrms@1/100 &1/1000

                      in common mode

                             ±14000V(DC+Peak AC)or 5000Vrms@1/100&1/1000

                      in differential mode

Output Voltage

-Max.Amplitude                ±7V(into 50KΩ load)

-Offset(typical)                 <±5mV

-Noise(typical)                 0.9mVrms

-Source Impedance(typical)       50Ω

CMRR(typical)                 -80dB@60Hz,-50dB@1MHz

Ambient Operating Temperaturc   -10 to 40°C

Ambient Storage Temperature     -30 to 70°C

Ambient Operating Humidity      25 to 85% RH

Ambient Storage Humidity        25 to 85% RH

Power Requirements

-Standard                      4xAA cells or 6VDC/200mA mains adaptor**

                              Or regulated 9VDC/120mA mains adaptor**

-Options                       Power leads

Length of BNC Cable            90cm

Length of lnput Leads            60cm

Weight                        500g

Dimension(LxWxH)             202mmx83mmx38mm
